Order Info:
Please specify which frequency you need when place the order. If no message left, we will ship 868Mhz frequency.
- LoraBee-868: 868Mhz , ship with glue sticker antenna , base on SX1276
- LoraBee-915: 915Mhz, ship with glue sticker antenna , base on SX1276
- LoraBee-433: 433Mhz, ship with glue sticker antenna, base on SX1278
Introduction:
The Dragino Lora BEE is a Lora module allows the user to send data and provides ultra-long range spread spectrum communication and high interference immunity whilst minimizing current consumption.
The Lora BEE is based on the SX1276/SX1278 transceiver.The Lora BEE targets professional wireless sensor network applications such as irrigation systems, smart metering, smart cities, smartphone detection,building automation, and so on.
This product can connect with the Lora/GPS Shield mother board to build a Lora/GPS Shield.
Features:
- Frequency Band: 868 MHZ/433 MHZ/915 MHZ(Pre-configure in factory)
- LoRa™ Modem
- FSK, GFSK, MSK, GMSK, LoRa™and OOK modulation
- XBee form factory
Lora Spec:
- 168 dB maximum link budget.
- +20 dBm - 100 mW constant RF output vs.
- +14 dBm high efficiency PA.
- Programmable bit rate up to 300 kbps.
- High sensitivity: down to -148 dBm.
- Bullet-proof front end: IIP3 = -12.5 dBm.
- Excellent blocking immunity.
- Low RX current of 10.3 mA, 200 nA register retention.
- Fully integrated synthesizer with a resolution of 61 Hz.
- FSK, GFSK, MSK, GMSK, LoRaTM and OOK modulation.
- Built-in bit synchronizer for clock recovery.
- Preamble detection.
- 127 dB Dynamic Range RSSI.
- Automatic RF Sense and CAD with ultra-fast AFC.
- Packet engine up to 256 bytes with CRC.
- Built-in temperature sensor and low battery indicator.
Package Includes:
- 1 x Lora Bee
- 1 x Glue Stick Antenna(868 MHZ, 433 MHZ or 915 MHZ depends on order)
- Environmental protection paper box
Useful Link:Manual
